But for that i should have installed HyerHDR?
But nevertheless.. I´m really happy that it´s working nowIn retrospect I should have tested the other Pi before, but to be honest i didn´t think that the Pi itself was the problem .
Yes, no HDR stream possible to Hyperion.NG
I suspected such already after all those tests.
Good it works 💪 now
Fine tweaking? Take your time, it can take days to have a nice glow you'll be satisfied with..
So, a big thank you to you Ambient_theater77 for your help and patience
No problem that's why we here, to point you in the right direction
-
it's possible to test the strip and SPI mosi with a sketch in Python.
You can run that and test.
-
data direction is arrow away from Raspi ?
-
okay!
so try the APA102 ledcontroller on SPI0.0 with standard settings.
then try the sk9822 ledcontroller with standard settings.
in one way or the other it should be come to life
wait, i've got another extra plan after that.
Cut the ledstrip until the faulty is gone and solder dataconnector on there, or use the old APA102
-
Vraagje 5: breedte HD107S ledstrip is tussen 10-12mm
10mm is30L/m
12mm is 60-144L/m
ik zou voor 60L/m gaan (fel genoeg maar niet over de top) als je strip minder als 10cm van de muur af is, bij meer ga dan voor 144L/m
Maar dan heb je wel een krachtige voeding nodig
Zie link :
De rest van je vragen aan pclin vragen svp 😀
-
Yes, spi is activated. I looked it up by connecting the sd-card to the pc and reading out the config file.
are you sure
Line is without the # ?
GND: Pin 6
CI: Pin 23
DI :Pin 19
SPI at Raspberry Pi GPIO Pinout
/dev/spidev0.0
GPIO10 is pin 19. Mosi
GPIO11 is pin 23 clk
GND connected from/to PSU/ledstrip/Raspi.
Try this:
/dev/spidev1.0
GPIO20 is pin 38. Mosi
GPIO21 is pin 40 clk
For spi1.0 activation add a line in config.txt below the dtparam spi line without the #
I have a Raspi 3b with mentioned setup, it ran... Ws2801 and APA102 and HD107S with Hyperbian 2.013 en later 2.016 distro with no problem whatsoever.
I hope you find the problem
this is mine
Code
Display MoreHyperion Server: - Build: (HEAD detached at 2.0.16) (Paulchen-Panther-cb85d2d/a93d79b-1705568419) - Build time: Jan 18 2024 09:30:40 - Git Remote: https://github.com/hyperion-project/hyperion.ng - Version: 2.0.16 - UI Lang: en (BrowserLang: nl-NL) - UI Access: expert - Avail Screen Cap.: dispmanx,framebuffer,qt - Avail Video Cap.: v4l2 - Avail Audio Cap.: audio - Avail Services: boblight,cec,effectengine,forwarder,flatbuffer,protobuffer,mDNS,SSDP,borderdetection - Config path: /home/pi/.hyperion - Database: read/write - Mode: Non-GUI Hyperion Server OS: - Distribution: Raspbian GNU/Linux 11 (bullseye) - Architecture: arm - CPU Model: ARMv7 Processor rev 4 (v7l) - CPU Type: Raspberry Pi 3 Model B Rev 1.2 - CPU Revision: 2a22082 - CPU Hardware: BCM2835 - Kernel: linux (5.15.32-v7+ (WS: 32)) - Root/Admin: false - Qt Version: 5.11.3 - Python Version: 3.7.3 - Browser: Mozilla/5.0 (Linux; arm_64; Android 14; SM-G991B)
-
No you don't have to login.
I think about it and it's possible (not having the experience with sk9822 strips) that the dataline voltage the Raspi puts out is too low and you need a levelshifter to crank up the datasignal from 3.3 to 5 volts.
Normally a SPI controlled APA102 strip works even without levelshifter direct on the GPIOs, the fact yours don't because a sk9822 is a clone strip of the APA102 is a sign....
Even my HD107S ledstrip runs out of the box WITHOUT levelshifter on APA102 ledcontroller flawlessly..
So I don't know, if you ledlayout is correct then...
you can only test your PSU. Common ground and not to high on voltage max 5.3
maybe somebody has a different option for you but for me that's it.
-
-
-
Quote
Okay, er wordt me al heel wat duidelijker, dankjewel!
[1] Maar mijn TV kan 120hz, moet je dan ook niet een splitter hebben die dit ook ondersteund? https://www.amazon.nl/dp/B0C739QQ4Q?tag=hyperioforum-21&&coliid=I2DNFNO8NE4L7O&colid=Y7YLBYT9OK29
[2]En die scaler, ik neem aan dat die alleen output 2 downscaled naar 1080p, en dat output 1 gewoon 4K blijft?
[3] Die Rullz HDMI/USB capturedevice, heb je hier een linkje van? Liefst Amazon indien mogeljik.
[4] Waarom gebruik je Hyperion.NG, die heeft toch problemen met HDR? Of is dit ondertussen opgelost?
[5] Als bijlage een layout van alle devices, die klopt zo dan denk ik?
Dank voor de Raspi 4 tip, dan neem ik die.
[6] Ik heb mijn Amazon lijst geupdatet, zou je deze nog eens willen doornemen?
Dank voor je hulp zover! geen dank, daar zijn we voor op dit opensource forum
1. als je graag 120Hz wilt hebben wel, ik hecht daar niet zo'n waarde aan want je receiver/AVR moet die resolutie en verversingssnelheid ook aankunnen anders heb je er nog niets aan
2, klopt helemaal, de Xolorspace 61121 doet precies dat wat je schetste.
3, wel van Aliexpress, niet van Amazon. >> link
kleur USB2.0 mini black
4, Ik gebruik geen HDR functies dus heb daar helemaal geen last van
5, Ja, ik zou voor een Meanwell voeding gaan die kan je ook met een potentiometer bijstellen in voltage >> RS series bv RS-100-5
6, gedaan, WS2812b werkt iets anders als bv een WS2801/APA102 of die ik nu heb met geweldige kleuren (ook wit) de HD107S
deze genoemd heb zijn allemaal 5 volt ledstrips, je hebt dan wel wat wattage nodig, ik gebruik voor 260 leds 100watt voeding van Meanwell
succes~!
-
Hee hallo.
Als je AVR (normaal) 2 outputs heeft gebruik ik inderdaad op mijn Denon maar 1 MAIN output.
Waarom? Omdat EDID/HDCP problemen anders voordoen met DRM content en/of wegvallende beelden of ambilight krijgt geen beelden binnen.
ik heb ook Denon en plug alle HDMI apparaten in de Denon.
Ik gebruik 1 MaIN HDMI OUT en breng die naar een splitter/downscaler van Xolorspace 4k ---> 1080p. Deze heeft 2 poorten,
Poort 1 Gaat naar 4k tv (direct)
Poort 2 EDID downscaler van 4k ---> 1080p
Type 61121 van Xolorspace
De 1080p gaat naar een Raspberry 3b die via een Rullz HDMI/USB capturedevice de beelden overbrengt.
Je hebt minimaal een HDCP2.2 splitter downscaler nodig met EDID mogelijkheid
In mijn geval zet ik die dus achter mijn AVR zodat ik meteen alle videosignalen te pakken heb en alles ook naar Hyperion.NG zendt ZONDER problemen met wegvallende beeld.
Dit kan dan bv voorkomen tijdens streamen van DRM content als Disney+/Netflix/Prime enz.
het klopt idd dat ik eerst 2 outputs gebruikte maar die setup gebruik ik niet meer omdat ik was overgestapt van AVR
Ik had eerst Onkyo en dat ging prima, na overstappen op de Denon x2000 AVR werkte dat niet meer en kon ik NiET 2 poorten tegelijk als MaIN gebruiken.
Omdat jij ook een Denon hebt zou ik dus voor mijn bovenstaand uitgelegd setup kiezen. (Om problemen te voorkomen)
Succes!
en voor je laatste vraag: ik zou minstens voor een Raspi 3 serie kiezen maar 4 is nog beter natuurlijk.
Het renderen van beelden kost namelijk de meeste kracht van de Raspi...
Ik gebruik ook maximaal 720p resolutie als setting IN Hyperion.NG, meer is echt niet nodig.
-
set user level as expert in right top corner of WebUI :8090
First check RGB setting in Led output--> Ledcontroller RGB byte order, if that's correct then,
go to remote control section, there you can change the colours in colour adjustment /gamma red_green_blue
Setting is LIVE (after reboot Hyperion they're gone) so you can safely alter everything you want.
Gamma level is normally around 2.2/2.4
Separate colours is possible step to alter.
When you have the good settings, then program them into Image Processing tab.
-
#dtparam=spi=on
Remove the # and save the config.txt
then reboot the Raspi
# before = Uncommented so NOT enabled, remove # will enable the line after reboot
enable line 9
Remove line 68
then save and reboot.
(You are commanding the SPI interface 2 different lines in config.txt, that's not going to work.)
-
-
Image:
higher decimation value, at least a 3
FPS not higher than 25
You can change the pixelformat
Resolution not to high
-
-
When it stops working, this is what the logs say.
2024-12-29T17:06:49.257Z [V4L2] (ERROR) Frame too small: 0 != 614400thats the problem, V4L2 driver is not receiving (correct) videodata
the problem is NOT in Hyperion but videostream stops, so i would suggest you check that grabber in windows
it has build-in HDCP and EDID so it looks, but still HDCP route can be a pain...
-
if you want to run WS2801 ledstrip with SPI then connect the strip directly to GPIO 10 and 11, thats SPIdev 0.0
SPI at Raspberry Pi GPIO Pinout
the whole lightberry led controller/level converter trough converting USB protocol is now absolete, you don't need it except the grabber for HDMI grab
-
ah, the old Hypercon days
follow this link, instead install Hyperbian version 2.016. It should run fine as long decimation is set at least 4 and FPS not higher than 25 i think.
